Step 3: Adding dev

In the last step, you engaged in the foundational work of refactoring your monolithic configuration into a set of reusable modules, still instantiated in a single root module. Now it’s time to leverage those newly develop skills to create new infrastructure.

One of the main advantages gained in creating infrastructure using IaC is improved reproducibility. The naive approach to creating new infrastructure is to directly copy and paste IaC to duplicate it, but there’s frequently advantage in packaging the infrastructure you’re going to replicate as a new pattern in your catalog so that you have a single source of truth for your shared IaC patterns.

In this step, you’ll take the infrastructure you’ve created so far, do one more refactor to encapsulate it as a single reusable module, then instantiate it a second time as a second dev environment.

Let’s introduce that new higher level module as a new module named best_cat. It will provision the s3, ddb, lambda and iam modules we added in the last step, and wire them together. This will give us a single entity that we can duplicate across environments.

catalog/modules/best_cat/main.tf
module "s3" {
source = "../s3"
name = var.name
force_destroy = var.force_destroy
}
module "ddb" {
source = "../ddb"
name = var.name
}
module "iam" {
source = "../iam"
name = var.name
aws_region = var.aws_region
s3_bucket_arn = module.s3.arn
dynamodb_table_arn = module.ddb.arn
}
module "lambda" {
source = "../lambda"
name = var.name
aws_region = var.aws_region
s3_bucket_name = module.s3.name
dynamodb_table_name = module.ddb.name
lambda_zip_file = var.lambda_zip_file
lambda_role_arn = module.iam.arn
}
catalog/modules/best_cat/outputs.tf
output "lambda_function_url" {
description = "URL of the Lambda function"
value = module.lambda.url
}
output "lambda_function_name" {
description = "Name of the Lambda function"
value = module.lambda.name
}
output "s3_bucket_name" {
description = "Name of the S3 bucket for static assets"
value = module.s3.name
}
output "s3_bucket_arn" {
description = "ARN of the S3 bucket for static assets"
value = module.s3.arn
}
output "dynamodb_table_name" {
description = "Name of the DynamoDB table for asset metadata"
value = module.ddb.name
}
output "dynamodb_table_arn" {
description = "ARN of the DynamoDB table for asset metadata"
value = module.ddb.arn
}
output "lambda_role_arn" {
description = "ARN of the Lambda execution role"
value = module.iam.arn
}
catalog/modules/best_cat/vars-optional.tf
variable "aws_region" {
description = "AWS region for all resources"
type = string
default = "us-east-1"
}
variable "force_destroy" {
description = "Force destroy S3 buckets (only set to true for testing or cleanup of demo environments)"
type = bool
default = false
}
catalog/modules/best_cat/vars-required.tf
variable "name" {
description = "Name used for all resources"
type = string
}
variable "lambda_zip_file" {
description = "Path to the Lambda function zip file"
type = string
}

Similar to what we did before with the constituent modules, we can simply replace the content in live with a reference to our new best_cat module.

live/main.tf
module "prod" {
source = "../catalog/modules/best_cat"
name = var.name
aws_region = var.aws_region
lambda_zip_file = var.lambda_zip_file
force_destroy = var.force_destroy
}

Once again, we get the scary tofu plan that tells us we would recreate all our infrastructure if we were to naively apply here:

Terminal window
$ tofu plan
...
Plan: 11 to add, 0 to change, 11 to destroy.
...

Luckily, we already know how to handle this. We’re going to update our moved.tf file to declare all the moves that need to be performed to transition the old addresses of resources to their new addresses.

live/moved.tf
moved {
from = module.ddb.aws_dynamodb_table.asset_metadata
to = module.prod.module.ddb.aws_dynamodb_table.asset_metadata
}
moved {
from = module.iam.aws_iam_policy.lambda_basic_execution
to = module.prod.module.iam.aws_iam_policy.lambda_basic_execution
}
moved {
from = module.iam.aws_iam_policy.lambda_dynamodb
to = module.prod.module.iam.aws_iam_policy.lambda_dynamodb
}
moved {
from = module.iam.aws_iam_policy.lambda_s3_read
to = module.prod.module.iam.aws_iam_policy.lambda_s3_read
}
moved {
from = module.iam.aws_iam_role.lambda_role
to = module.prod.module.iam.aws_iam_role.lambda_role
}
moved {
from = module.iam.aws_iam_role_policy_attachment.lambda_basic_execution
to = module.prod.module.iam.aws_iam_role_policy_attachment.lambda_basic_execution
}
moved {
from = module.iam.aws_iam_role_policy_attachment.lambda_dynamodb
to = module.prod.module.iam.aws_iam_role_policy_attachment.lambda_dynamodb
}
moved {
from = module.iam.aws_iam_role_policy_attachment.lambda_s3_read
to = module.prod.module.iam.aws_iam_role_policy_attachment.lambda_s3_read
}
moved {
from = module.lambda.aws_lambda_function.main
to = module.prod.module.lambda.aws_lambda_function.main
}
moved {
from = module.lambda.aws_lambda_function_url.main
to = module.prod.module.lambda.aws_lambda_function_url.main
}
moved {
from = module.s3.aws_s3_bucket.static_assets
to = module.prod.module.s3.aws_s3_bucket.static_assets
}

Our apply now successfully completes without doing anything!

$ tofu apply
...
Apply complete! Resources: 0 added, 0 changed, 0 destroyed.
...

Now the stage is set to add the additional dev environment. We can do that by duplicating the prod module, and labeling the new module block dev (you’ll also want to add a little suffix to the end of the name input to avoid naming collisions).

live/main.tf
module "dev" {
source = "../catalog/modules/best_cat"
name = "${var.name}-dev"
aws_region = var.aws_region
lambda_zip_file = var.lambda_zip_file
force_destroy = var.force_destroy
}
module "prod" {
source = "../catalog/modules/best_cat"
name = var.name
aws_region = var.aws_region
lambda_zip_file = var.lambda_zip_file
force_destroy = var.force_destroy
}

We also need to expose some of the outputs of the new dev module, but if we just duplicated all the prod outputs, we’d end up with a massive wall of outputs that would be hard to parse. Luckily, we only need two outputs to be externally accessible per environment, so we can drop a bunch of outputs to streamline things.

live/outputs.tf
output "dev_lambda_function_url" {
description = "URL of the Lambda function"
value = module.dev.lambda_function_url
}
output "dev_s3_bucket_name" {
description = "Name of the S3 bucket for static assets"
value = module.dev.s3_bucket_name
}
output "prod_lambda_function_url" {
description = "URL of the Lambda function"
value = module.prod.lambda_function_url
}
output "prod_s3_bucket_name" {
description = "Name of the S3 bucket for static assets"
value = module.prod.s3_bucket_name
}

We should have a project layout that looks like this now:

  • Directorycatalog
    • Directorymodules
      • Directorybest_cat
        • main.tf
        • outputs.tf
        • vars-optional.tf
        • vars-required.tf
      • Directoryddb
        • main.tf
        • outputs.tf
        • vars-required.tf
        • versions.tf
      • Directoryiam
        • data.tf
        • main.tf
        • outputs.tf
        • vars-required.tf
        • versions.tf
      • Directorylambda
        • main.tf
        • outputs.tf
        • vars-optional.tf
        • vars-required.tf
        • versions.tf
      • Directorys3
        • main.tf
        • outputs.tf
        • vars-optional.tf
        • vars-required.tf
        • versions.tf
  • Directorylive
    • backend.tf
    • main.tf
    • moved.tf
    • outputs.tf
    • providers.tf
    • vars-optional.tf
    • vars-required.tf
    • versions.tf

Now we can deploy our changes.

Terminal window
# live
tofu init
tofu apply

We now have our new, fresh dev environment!

fresh-dev-environment

We have officially reached the stage where we’re hitting risk increase due to our Terralith! This is the configuration of IaC that a lot of infrastructure estates grow to naturally as they tack on more resources and add environments. It’s a tipping point in maintainability that is best caught early, and addressed.

We gained the ability to easily provision new infrastructure via reusable modules and could simply copy and paste (then season to taste) some configuration in our live/main.tf file. We also had a single source of truth for representing all the infrastructure that we were provisioning, in both the reusable module, and our live OpenTofu root module.

We traded that for additional risk incurred, as every apply or destroy now has the potential to modify or destroy multiple environments, and you have to carefully avoid misconfiguration by reading plans (and trusting that they’re accurate) to avoid accidentally damaging the wrong environment. Furthermore, you also have to be very careful that you only modify the resources that you intend to modify within a given environment when you make updates to it (are you accidentally destroying your database when attempting a tagging update for your Lambda function?). The reason for this is that all your resources are in the same state file. OpenTofu has to make one atomic change to that single state file with every update, so all the resources in state are at risk when any change is made.

For your information, there are tools out there, like OPA that enable automated reasoning about plan risk, but those tools are typically adopted by more advanced infrastructure teams, and there is typically a significant amount of overhead in authoring and maintaining the policies that assess plan risk (and driving behavior off those assessments). There are hints at the end of this guide to point those capabilities out and encourage your own exploration on this topic.

Generally, the approach that teams take to structurally reduce this risk is to start to break down the Terralith into separate root modules, each with their own state. This gives teams confidence that they can only modify dev when they set their current working directory to the dev root module, and prod when their current working directory is the prod root module. When thinking through access control, this can also be convenient, as you can segment the access control that you use for one root module from another. Teams frequently configure their setups so that they need to explicitly use different credentials via role assumption, etc. when running commands in root modules related to different environments (e.g. dev vs prod ) to avoid accidental updates in the wrong environment.

The downside to that approach, as we’ll see in the next step, is that it does increase the management burden of orchestrating and maintaining your IaC, and additional tooling like Terragrunt is a good way to handle that additional orchestration burden.

You’ve successfully spun up a second, isolated development environment by reusing your new best_cat module. However, this is also the point where the Terralith design pattern starts to incur some serious drawbacks. At this stage, all your infrastructure for both your environments (dev and prod) now lives in a single state file. This introduces significant risk. A small mistake intended for dev could potentially damage or destroy your prod environment because OpenTofu sees it all as one atomic unit to manage, and you’re responsible for reasoning about the generated plan to see if you should proceed with an apply. The next step is the most critical step in maturing your IaC estate (as far as this guide is concerned) as you break this monolith apart to limit the blast radius of your updates.
